ASSEMBLY AND INSTALLATION
27
6
2
Secure the REAR SASH to the seat of the
REAR CABINET using the (4) M4 xings
as shown.
3
Secure the MID SASH using the (4) M4
xings to secure the connection between
the two FLOOR PANELS
4
Secure the SIDE SASH L as shown using the (4) M8 xings.
FIG. 6-5b
FIG. 6-5c
FIG. 6-5d
