122
PARTS LIST
18
ITEM NO PART NO DESCRIPTION
*1 TS-1000UK ASSY MONITOR CABI 1
*3 TS-3000UK ASSY REAR CABINET 1
*20 421-7988-91UK STICKER SERIAL NUMBER UK 2
*21 440-WS0100UK WARNING LABEL FORK HERE 2
*22 440-DS0010UK LABEL DANGER HI VOLT
*23 LB1046 LABEL TESTED FOR ELEC. SAFETY 2
*24 LB1130 LABEL WEEE WHEELIE BIN 4
*25 440-CS0186-01UK STICKER CAUTION EPILEPSY 3
*26 440-CS0010UK LABEL CAUTION GENERIC 1
*101 220-5374-01 DOOR DFMD W/FR&LOCK C120 UNIV 1
*102 220-5575UK LOCK (J9117) KEY TO LIKE 22MM W CAM 1
*103 OS1247 ALUMINIUM STICKY CLIP ASK-3 3
1
*105 220-5727-01B DOOR CASH H.S. STS 1
**106 220-5575-280UK LOCK(J9117) 28MM W/O CAM
*401 TS-INST-TH ASSY INST TS TH 1
*410 PK0521 PALLET TS TH MON 1
*411 PK0484 SHRINK WRAP DV DX 1
*412 PK0517 PALLET TS TH REAR
1 TOP ASSY TRANSFORMERS TH (TS-0001UK) (D-1/1)
Please note: The location of all labels can be found in Chapter 1 of this manual.
