22
ASSEMBLY AND INSTALLATION
6
5
.Secure the exhaust pipe using the (3) M8
xings on the interior of the cabinet. Follow the
same procedure to t the remaining Exhaust.
FIG. 6-2e
FIG. 6-2d
4
Attach the connector between the cabinet
and the Exhaust Pipe via the hole shown.
3
Using the (2) M8 xings removed in Step
1, secure the Exhaust Pipe to the top of the
REAR CABINET.
FIG. 6-2c
