38
ASSEMBLY AND INSTALLATION
6
1
Move the product to the installation site. If the product is to be installed near a wall, secure enough passage-
way space for players to access the seat. You must also secure a 20 cm space between the back wall and the
back of the cabinet for ventilation.
2
Bring the adjusters into direct contact with the oor. Use a wrench to align the height of the adjusters until
the cabinet is perfectly level.
3
After setting, turn adjuster nuts upwards to tighten them and secure adjuster heights.
FIG. 6-13b Aligning the Adjusters
You must secure a minimum 20cm ventilation space between the back of the Gun Cabinet and the wall.
FIG. 6-13c Ventilation Space
20cm
ADJUSTER
ADJUSTER CASTER
About 5 mm
Tighten nut
upwards.
To Next Page
