Settings
74 A0785-150 HBM: public T10FS
Important
When viewed from above, switch S8 is behind switch S7
in the opened stator housing.
Switch S8
(behind switch S7)
LED L4
Fig. 8.15 Switch S8; optimizing the reference pulse
