HBM T10FS User Manual

Dimensions
80 A0785-150 HBM: public T10FS
Measuring
range
Dimensions (in mm; 1 mm = 0.03937 inches)
b
1
b
2
b
3
b
4+0.4
b
5
b
6
b
7
b
8
b
9
x
S
Y
100 N⋅m /
200 N⋅m
17.5 60 18 2 4 46.3 13.7 47.2 47.2 30 M8
500 N⋅m /
1 kN⋅m
17.5 60 18 2 4 46.3 13.7 45.5 45 30 M10
2 kN⋅m /
3 kN⋅m
20,5 64 20 2.5 4 48.8 15.2 47.5 47 32 M12
5 kN⋅m 22.5 84 26 2.8 3 67.8 16.2 62.7 62.7 42 M14
10 kN⋅m 28.5 92 30 3.5 4 72.8 19.2 66.7 66.7 46 M16
Measuring
range
Dimensions (in mm; 1 mm = 0.03937 inches)
∅d
A
∅d
B
∅d
C
∅d
F
∅d
G
∅d
K
∅d
S
C12
∅d
Z
∅d
za g5
∅d
zi
H6
100 N⋅m /
200 N⋅m
119 84 99 101 110 14 8.2 131 57 57
500 N⋅m /
1 kN⋅m
139 101.5 120 124 133 17 10 151 75 75
2 kN⋅m /
3 kN⋅m
175 130 155 160 169 19 12 187 90 90
5 kN⋅m 209 155.5 180 188 - 22 14.2 221 110 110
10 kN⋅m 256 196 222 230 - 26 17 269 140 140
