HT# 059299-00 A

1 2 3 4 5 6 7 8

Control Stages

1 & 2

Control Stages

3 & 4

Control Stages

5 & 6

Control Stages

7 & 8

Modulating Output Cards:

• 135Ω Output Card (HT# 900203-135)

• Current and Volt Output Cards

(HT# 900203-C/V)

Fuse

RS485 connects to

(MMOD, HWRQ, or

MPCQ Platinum)

Dip Switches

determine Extension

number

EXT1 Dip1=ON, DIP2=ON

EXT2 Dip1=OFF, DIP2=ON


