HT# 059299-00 A
STAGE A SETTINGS
Mode Auto
Ignition% 1%
Mod Start 80%
Copy Settings
------- STAGE A -------
Ignition Point
1%
[
]
- STAGE A MANUAL -
50%
[ ]
COPY STAGE A
SETTINGS
to all Stages
--- STAGE A MODE---
Auto
Manual
Standby
Off
On
--- STAGE A MODE---
Auto
Manual
Standby
Off
On
------- STAGE A -------
Modulation Start
80%
[
]
STAGE B SETTINGS
Mode Auto
Ignition% 1%
Mod Start 80%
STAGE MENU
• This menu helps set the total number of active stages In addition, it
offers the option to adjust the low re setting and the lead percent ring at
which the lag stage starts
• In most installations, all stage adjustments are the same However, the
Multi-MOD Platinum offers a customized adjustment for each stage to
satisfy installations with different types of boilers
• When all the stages are the same type of boiler, congure Stage "A"
settings then copy the settings to the rest of the stages Everything but
the Mode will be copied
STAGE A SETTINGS
Mode Auto
Ignition% 1%
Mod Start 80%
Copy Settings
• Pressing the Stage button scrolls though the Stages' menus
• Pressing the Next button displays the next adjustment
STAGE MENU/Mode
• The Multi-MOD Platinum only controls the modulation of stages set to
Auto or (after a delay) those set to Standby None of the other settings
are recommended for stages connected to active units
--- STAGE A MODE---
Auto
Manual
Standby
Off
On
• The Multi-MOD Platinum controls the stage's operation to maintain the
target
• Only stages set to Auto can be lead stages
Any Stage not used ITS MODE
MUST BE SET TO OFF
To Next Page
