HT# 059299-00 A
Shifting from Night to Day
• The control uses the Day settings instead of the current Night settings
The control stays in the Day mode until the control is shifted again or
until the next programmed Night Time The display will show "DAY SHF"
to indicate this status
Shifting from Day to Night
• The control uses the Night settings instead of the current Day settings
The control stays in the Night mode until the control is shifted again or
until the next programmed Day Time The display will show "NGT SHF"
to indicate this status
Shifting to Extended Day
• The control uses the Day settings for an extended period The extended
period is set by the Extend Day Time The display will show "DAY EXT"
to indicate this status When the control is manually shifted to Extended
Day, the Display will alternate between the "DAY EXT" and the remaining
extended time balance in minutes "DAY 89" to indicate this status After
the extended period, the control reverts to the schedule
• The Shift to Extended Day option is available to anyone with access to
the control A Password restriction does not affect this option
Shifting to Schedule
• This option exists the Shifting and resumes the scheduled operation
• The Shift to Schedule option is available to anyone with access to the
control Password restrictions does not affect this option
- EXTEND DAY TIME-
90 Min
[
]
/<Schedules>/Day Night Schedule
• Use this setting to set up to 4 Day Time and 4 Night Time (Setback)
settings per each day of the week
------ SCHEDULES ------
MON # 1
Day Time 6:00Am
Night Time 10:00Pm
• If the Boost feature is being used, it uses the Day Time #1 setting See
"Boost and Early Shutdown" on page 34
• The Night Time setting reduces the target temperature by the Setback
setting Furthermore, if the ESD is used, the control uses the last Night
Time in calculating the ESD
#1
Day 6:00AM 6:00AM 6:00AM 6:00AM 7:00AM **:** **:**
Night 10:00PM
♦♦
10:00PM
♦♦
10:00PM
♦♦
10:00PM
♦♦
11:00AM **:** **:**
#2
Day **:** **:** **:** **:** 1:00PM 8:00AM
♦
**:**
Night **:** **:** **:** **:** 4:00PM 4:00PM
♦♦
**:**
#3
Day **:** **:** **:** **:** 6:00PM **:** **:**
Night **:** **:** **:** **:** 10:00PM
♦♦
**:** **:**
#4
Day **:** **:** **:** **:** **:** **:** **:**
Night **:** **:** **:** **:** **:** **:** **:**
♦ No boost will take effect
♦♦ Early Shut Down ends Night Schedule begins
