HT# 059299-00 A
Setting an Initial Pilot Program eases the installation and conguration of the Multi-MOD Platinum and gives
the opportunity to use many of the energy saving features while providing comfort
The program should consist of the following:
• Select the features that your system can utilize,
• Making sure you are ordering the right control and accessories (Multi-MOD Platinums do not come with
sensors or stage relays, these items must be ordered separately,
• Install and wire the Control,
• Set the System Startup menu,
• Set the System Settings,
• Set the Stages and their rotation,
• Set the Schedules
• Adjust the Reset Ratio and Water Offset (In Reset Mode Only) or set the Set Point,
The following are for communication equipped controls only:
• If the control had communication, connect and install the communication,
• If the control had Internet communication, install and wire the sensors
If you need the Multi-MOD Platinum to do additional tasks that either is not listed or do not know
how to congure them, contact Heat-Timer Corp Sales Department either by Phone (973)575-4004,
E-mail to: support@heat-timercom, or using the web contact form http://wwwheat-timercom
