heat-timer Multi-MOD Platinum User Manual



HT# 059299-00 A

------ SETTINGS ------
Shift
<System Settings>
<Schedules>
<Maintenance>
<System Startup>
- SYSTEM SETTINGS -
Season Winter
Set Point 70
F
Target Offset +0
F
Reset Ratio 1:1
Outdoor Cutoff 65
F
Sys Run-On 0m
<More Settings>
---- SEASON ----
Winter
Summer
--- BOOST MODE ---
Off
Vari
Vari+ESD
--- LEAD STAGE ---
A
B
C
LEAD AUTO ROTATE
Manual
Time
Last-On
SHIFT FROM NIGHT TO
Extended Day 90m
Day
Schedule
---- SYSTEM RUN-ON ---
0min
[
]
-- MINIMUM TARGET --
80
F
[
]
--- SETBACK ---
0 F
[
]
--- PURGE DELAY ---
1.0m
[
]
--- LAG DELAY ---
0m
[
]
--- STANDBY DELAY ---
10m
[
]
AUTO ROTATE PERIOD
24 Hrs
[
]
- SOFT OFF DELAY -
45s
[
]
- LAST STAGE HOLD -
0 F
[
]
-- MAXIMUM TARGET --
240
F
[
]
------- OFFSET -------
+0 F
[ ]
BOOST ADJUSTMENT
+0 F
[ ]
--- SET POINT--
70 F
[ ]
- OUTDOOR CUTOFF -
65
F
[
]
SYSTEM SETTINGS 2
Min Target 80 F
Max Target 200
F
Setback 0
F
Boost Mode Vari
<Stage Settings>
<Remote Interface>
-- STAGE SETTINGS --
Purge Delay 1.0m
Lag Delay 0m
Standby Delay 10m
Soft-Off Delay 45s
Last Stage Hold 0
F
<Lead Settings>
-- LEAD SETTINGS --
Lead Stage D
Rotate Mode Time
System Settings Pg 32
System Settings 2 Pg 32
---- RESET RATIO ----
1.00 OD=4.00 Sys
1.00 OD=3.00 Sys
1.00 OD=2.00 Sys
1.00 OD=1.50 Sys
1.00 OD=1.25 Sys
1.00 OD=1.00 Sys
1.25 OD=1.00 Sys
1.50 OD=1.00 Sys
2.00 OD=1.00 Sys
3.00 OD=1.00 Sys
4.00 OD=1.00 Sys
Stage Modulation Settings Pg 36
Lead Settings Pg 38
Reset
Reset
Set Point
Time
