• Check the 120VAC power input to the control Turn power to the control off and back on
• Make sure that the Green Ground Screw is connected to a reliable Earth Ground
• Make sure that all wiring is fed to the control through the bottom knockouts and that no voltage wiring is
running behind the control board
• If the sensor reads Open, short the sensor input terminals The display should read
Short If it does,
then the problem is with the sensor wiring If it doesn’t, then the control may be damaged
• If the sensor reads Short, remove the wires from the input terminals The display should read
Open If it
does, then the problem is with the sensor wiring If it doesn’t, the control may be damaged
• Remove the wires from the input terminals The display should change to read
Open If it doesn’t, the
Multi-MOD Platinum may be damaged
• Otherwise, take an ohm reading across the detached sensor wires The reading should correspond to
the Temperature Sensor Chart If the difference is within 5°F adjust the sensor trim See "System and
Outdoor Sensor Trim" on page 47 Otherwise, the sensor may be damaged
OPEN 150000
-30 -34 117720
-20 -29 82823
-10 -23 59076
0 -18 42683
10 -12 31215
20 -7 23089
25 -4 19939
30 -1 17264
35 2 14985
40 4 13040
45 7 11374
50 10 9944
55 13 8714
60 16 7653
70 21 5941
80 27 4649
90 32 3667
100 38 2914
110 43 2332
120 49 1879
130 54 1524
140 60 1243
150 66 1021
160 71 842
170 77 699
180 82 583
190 88 489
200 93 412
210 99 349
220 104 297
230 110 253
240 116 217
250 121 187
SHORT 100
• Check the pressure range set in the System Startup If the reading is still not correct remove the wires
from input terminals S and + (A5 & A6) Check for DC voltage across the two terminals If voltage
between 5 and 36 is not present, the control may be damaged
• Connect the black sensor wire to terminal + (A6) Put an amp meter in series by connecting the meter's
(-) to the sensor's detached red wire, and connect the meter's (+) side to the S (A5) input terminal The
mA reading should correspond to the Pressure Sensor Chart If it doesn’t, the sensor may be damaged
2 Open
4 0 0 0 0
72 6 20 40 60
104 12 40 80 120
136 18 60 120 180
168 24 80 160 240
20 30 100 100 300
22 Short
