HT# 059299-00 A
/<System Settings>
• System Settings menus adjust and ne-tune the system to match the building
or application specic characteristics for enhanced comfort and more fuel
savings
/<System Settings>/Season when in Winter setting
/Season when in Summer setting
• The Season is used to turn off the outputs when in the off-season period
When Heating is selected as the Heat/Cool Mode, the outputs are turned
off when the Season is set to Summer However, when Cooling is
selected, the outputs are turned off when the Season is set to Winter
• When in the off-season period, it is a good practice to switch the
Multi-MOD Platinum to the proper season setting instead of turning the
control off
---- SEASON ----
Winter
Summer
The Season setting has no
effect on outputs energized
for a DHW Call
/<System Settings>/ Set Point
• The Multi-MOD Platinum modulates the stages to maintain the system
temperature/pressure around the Set Point
• The system is expected to uctuate around the set point The amount of
uctuation depends on the control settings
• If the EMS Mode was Enabled, the Set Point will be set by the EMS/BMS
system and will be available as a read only
--- SET POINT--
70 F
[ ]
/<System Settings>/ Set Point
• This feature turns off the outputs when the outdoor temperature rises
above the Outdoor Cutoff in Heating Mode In Cooling Mode, it turns
off the outputs when the outdoor temperature drops below the Outdoor
Cutoff See "Heat/Cool Mode" on page 28
• In addition to the operable temperature range, the Outdoor Cutoff can
be set to ON or OFF If ON was selected, the control will modulate the
stages to hold the target set point regardless of the outdoor temperature
The System output will be active at all times
• If OFF was selected, the System output and all the stages will be off
- OUTDOOR CUTOFF -
65
F
[
]
• Outdoor Reset adjusts the target temperature based on the outdoor
temperature See "Reset Ratio/Outdoor Reset" on page 5
• The target temperature value depends on the following settings:
○ Reset Ratio
○ Target Offset
○ Minimum Target
○ Maximum Target
