HT# 059299-00 A



CPU Board

Battery

Ethernet

RS485

Main Board

Control Stages

A & B

Control Stages

C & D

RS485

Communication Board

(HT# 900234-20-XXX)

Fuse

Battery

HT#020002-00

Ethernet (RJ45) connects to:

• Internet

• BACnet IP

Green RS485 connects to:

• MSI HUB interface

RS485 connects to

Extensions only.

Cables are provided with

Extension

Modulating Output Cards:

• 135Ω Output Card (HT# 900203-135)

• Current and Volt Output Cards

(HT# 900203-C/V)

Black RS485 connects to:

• BACnet MSTP

• Modbus RTU

• Network Manager
