64
î Be sure to turn the ignition switch “OFF”
when replacing the bulb.
î Do not use bulbs other than that specified.
î After installing a new bulb, check that the
lamp operates properly.
Headlamp/Position lamp bulb
î Remove the headlamp case (page 37).
î Disconnect the headlamp connector (1)
and position lamp connector (2).
î Remove the headlamp bulb (5) without
turning.
î Remove the position lamp bulb (6) from
both sides of the headlamp case.
î Loosen the screw and release the clip (4)
from its position.
î Remove the body cover (page 32).
î Remove the fuel drain tube (1).
Tail/Stop lamp LED unit
î Disconnect the tail/stop lamp connectors.
î Remove the centre compartment (page
31).
î Remove the fuel tank lid lock cable from the
guide (2).
î Remove the tail/stop lamp unit from
the body cover by removing the screws (3).
(3) Dust cover (4) Clip
4
3
(5) Headlamp bulb (6) Position lamp bulb
5
6
î Install a new bulb in the reverse order of
removal.
î Remove the dust cover (3).
2
1
(1) Headlamp connector
(2) Position lamp connector
To Next Page
