65
(1) Fuel drain tube(2) Guide (3) Screws
3
î Install a new tail/stop lamp unit in the
reverse order of removal.
Rear turn signal bulb
î Remove the bulb (1) by turning it to
counterclockwise direction.
î Insert hand from body cover rear side,
above rear fender area and remove turn
signal bulb holder (1) by turning counter
clockwise.
(1) Bulb holder (2) Rear turn signal lamp bulb
2
1
î Install a new bulb in the reverse order of
removal.
Clean your scooter regularly to protect the
surface finishes and inspect for damage, wear
and oil leakage.
CLEANING
Avoid cleaning products that are not
specifically designed for scooter or automobile
surfaces. They may contain harsh detergents
or chemical solvents that could damage the
metal, paint and plastic parts on your scooter.
î Install a new bulb in the reverse order of
removal.
î Insert hand from body cover front side,
above front fender area and remove turn
signal bulb holder (1) by turning counter
clockwise.
Front turn signal bulb
î Remove the bulb (1) by turning it to
counterclockwise direction.
(1) Front turn signal lamp bulb
1
2
1
