Hex ezCAN for CAN-bus-equipped Motorcycles
_________________________________________________________________________________________________
_________________________________________________________________________________________________
© Hex Innovate (UK) Ltd. Page 32 of 60 ezCAN 2408.x
3. To control the on/off function of the Aux 1 lights only, click the
Toggle only Auxiliary Lights One on/off radio button.
4. To control the on/off function of the Aux 1 lights and Aux 2 lights
(in other words, to make the Aux 2 lights mimic the on/off condition
of the Aux 1 lights), click the Toggle both Auxiliary Lights One &
Two on/off radio button.
5. Click OK.
5.1.3.3.2 If no aftermarket Aux light switch is installed (non-Gobi KTM models only)
If no aftermarket Auxiliary light switch is installed, use the motorcycle’s
DRL function to switch the auxiliary lights ON or OFF by doing the steps
that follow:
1. Navigate to the DRL option in your KTM’s instrument display
Settings menu.
2. Toggle the DRL function twice. You can use either of the following
sequences:
 ON  OFF  ON  OFF  ON
 OFF  ON  OFF  ON  OFF
Switching the
auxiliary lights on or
off
1. Stop the motorcycle.
2. Navigate to the DRL option in the KTM instrument
display’s Settings menu.
3. Toggle the DRL function twice.
Adjusting Aux 1 or
Aux 2 light brightness
This can only be done using the Auxiliary Lights sections of
the ezCAN configuration software.
Strobing Aux lights on
‘Flash-to-pass’
Click the motorcycle’s ‘Flash-to-pass’ button three times.
Note that to be active, this function must be enabled using
the ezCAN configuration interface.
5.1.3.3.3 If the Hex UP-DOWN switch is installed (non-Gobi KTM models only)
The Hex UP-DOWN switch for controlling Aux lights is available as an
accessory from Hex Innovate. To purchase a Hex UP-DOWN switch, click
here.
The Hex UP-DOWN switch option can be enabled using the Aux Lights
Extra Settings menu. To configure the ezCAN to accept control input from
a Hex UP-DOWN switch, do the steps that follow:
1. Click the drop-down menu button in the upper right corner of the
Auxiliary Lights One or Auxiliary Lights Two sections (below).
2. Click the Extra Settings option.
 The auxiliary lights Extra Settings menu will be shown.
