Connection
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │104
E.5.3 COMPUTER SETUP
Ensure that the Ethernet Local Network TCP/IPv4 is set to “Obtain an IP address automatically” (DHCP)
(default).
TCP/IP Detailed steps:
1. Access the network settings: press the Windows® logo touch on the keyboard and type
in “ncpa.cpl”
2. Right click on “Local Network” and select “Properties”:
3. Select Internet Protocol Version 4 (TCP/IPv4) > Properties
