B.9 EXTERNAL LASER SCANNERS

B.9.1 HP-L-20.8

LEDs - Sensor

LASER

Laser status (on/off)

POWER

Sensor power status (on/off)

LEDs - Control Pack

LASER ON

The laser is currently active

PC COM

Controller and PC communication status (ok/off)

SENSOR COM

Sensor and controller communication status (ok/off)

SENSOR POWER

Sensor power status (on/off)

UNIT POWER

Control unit power status (on/off)
