Hexagon Absolute Arm RS5 User Manual

Components description
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │59
Home Dock
For a secured home position of the arm, the wrist is equipped with a blocking system. The Home Dock
avoids the wrist from moving, and the probe or scanner from hitting the base of the arm.
1. Bring the arm to its home position.
2. 7 Axes wrists: Turn the wrist as shown
3. Position the notch of the wrist on stop on the Home Dock.
