Measure with the arm
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │124
F.1.7 HOW TO USE THE ARM BUTTONS
Whatever the configuration is, the buttons present on the wrist have dedicated aims. The Trigger Button is
the “measurement” button, and the 3-State button, used for control.
Trigger Button (BT)
This main button is the one used to take points, start or stop scanning…
3-State Button (B3S)
This special button can be used for validating or cancelling (points, messages…) or for controlling the Quick
Access Menu.
Usually, the button is defined as the following:
Fig. 39 : 3-State button
However, depending on the software, the use of the buttons may be different. Please refer to the appendix
for specific application software setup.
