D.3 TUBE INSPECTION ARM INSTALLATION

Arm Tube Raisers

The tube inspection arm special configuration is installed on top of a specific raiser, available in 2 sizes

(250mm and 500mm):

NOTICE

Low quality work floor: loss of accuracy

Always ensure that the support or surface on which the raiser is fixed can guarantee a good stability.

For more details regarding the raisers, please refer to § Special raisers

Arm Tube installation-uninstallation

Due to its stronger counterbalance, the tube inspection arm must be installed or uninstalled by a trained

people.
