Components description
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │26
B.2 BASE – CONTROL PACK
B.2.1 BASE DESCRIPTION
Front panel
Fig. 17 : Base-Front
a. Sound Speaker
b. Power-On Button/Light
c. Status Pictograms
Back panel - Control Pack (except FP4)
Fig. 18 : Base-Back
a. Ambient light sensor
b. Left battery socket (CP3 only)
c. Access to unlock the left battery socket
d. Right battery socket (CP2 / CP3 only)
e. Access to unlock the right battery socket
f. USB connector to computer
g. Accessory connector (CP1 / CP2 / CP3 only)
h. DC power in
b
c
a
f
g
d
b
a
h
e
c
