Absolute Arm presentation

H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │15

Item

Description

1200

6 axes

7 axes

1200

6 axes

7 axes

6 axes

7 axes

Verification. bar



✓

Quick

Installation

Guide

(full documentation on

installation disk)

✓

Installation stick

Contains Software

installation and product

documentation.

✓

Certification

ISO 10360-12

✓

ISO 10360-02



A catalogue with the complete list of accessories is available on the provided media or on

the www.HexagonMI.com web site
