Hexagon Absolute Arm RS5 User Manual

Appendix
H00007091 - Absolute Arm User Manual │Version 5.2.0 (2019-03-07) │225
Technical specifications
Standard
EN 60825-1 : 2007
TCPIP address
192.168.178.200
TCPIP Port
40
class
2M
Wave length
650nm
Line width (mid field)
80 mm (min 65 / max 98)
Point acquisition rate
45 000 points / sec
Points per line
750
Line rate
60 Hz
Min Point spacing
0.08 mm
Stand off
133 mm ± 45mm
Warm up time
< 10 min
RMS Average
0.020 mm
Distance variation within
10mm
0.015 mm
Laser power adjustment
Semi-automatic
Output power
< 1mW
Admission angle
60° fan angle
Operating Temperature
5°C to +40°C (32°F – 122°F)(open double check)
Storage Temperature
-30°C to +70°C
Altitude
up to 2000 m
Shock without case
50 mm drop (used for design validation)
Shock in transport case
1m drop
Vibration in transport case
ISO 9022-3:1998 10 to 150 Hz ± 0.15 mm, 2g. 20 sweeps/ axis at 1
octave/min
Humidity
maximum 95% non-condensing
IP Rating
IP 50
Weight
322 g
2-sigma accuracy
0.038 mm
