HIKVISION DS-K1TA70 Series - Page 35

Type 2
Note
The re system (NO and COM, normally open when powering o) is connected with the lock and
the power supply in series. When an re alarm is triggered, the door remains open. In normal
mes, NO and COM are closed.
Figure 4-6 Wiring Device
DS-K1TA70 Series Face Recognion Terminal User Manual
19
