Affinity® 4 Birthing Bed Instructions for Use (USR025 REV 13) 5
Nurse call (refer to the
section titled “Nurse
Call (Optional)” on
page 12 for nurse call
switch information).
Do Not Push—do not
use the headboard to
push the bed. On wood
headboards without
integrated push
handles.
Lockout control
status—when the
lockout control status
light is on, the lockout
function is activated.
Equipotentiality. Beds
with grounding post
only.
Identifying mains fuse. Alternating current
Do not throw away—
indicates the need to
recycle the item in
accordance with local
regulations.
Manufacturer or
distributor complies
with the Waste Electric
and Electronic
Equipment Directive
2002/96/EC.
B through D Model Beds
According to IEC 60529,
rating for protection
against fluid ingress
and identified as
equipment that is
protected against
vertically falling water
when tilted up to 15°.
Room Light On/Off
control.
CAUTION: Consult
accompanying
documents.
Back section mattress
(lumbar) control.
Certified by
Underwriters
Laboratories, Inc. (Serial
Numbers after
H297AA4665 and up to
Serial Numbers
beginning with
M170AA; as being in
accordance with that
which is shown in the
Classification and
Standards table (see
page 48)
Seat section mattress
control (optional).
Symbol Description Symbol Description
Pb
