Bed Frame Features
14 Affinity® 4 Birthing Bed Instructions for Use (USR025 REV 13)
AUTOMATIC TILT
• As the head section is raised, the seat
section gradually tilts up from 0° to 15°.
• As the head section is lowered, the seat
section gradually returns to a flat position.
CPR RELEASE
The CPR Release enables the caregiver to save valuable time in an
emergency. When activated, the CPR Release automatically lowers the
head and seat section to the flat position, which creates a firm surface to
support a CPR board.
To activate—Pull the emergency CPR Release handle on either side of
the bed. Release your hand when the head section is down to the lowest
position.
FLUID BASIN
The fluid basin is removable. and easily removed for cleaning.
To Remove/Replace the lift-off or slide-off foot section fluid
basin
1. Pull the fluid basin straight out.
2. Slide the basin straight into the holding devices.
3. Shake the basin gently to ensure it is securely seated.
To Remove/Replace the Stow and Go® Foot Section fluid basin
1. Pull the basin up and out of the foot section.
2. Put the basin down in to the opening in the foot section.
FOOT SECTION (LIFT-OFF OR SLIDE-OFF)
To Remove
The foot section can be removed by using the following methods:
If the foot section height can be adjusted:
1. Adjust the foot section so that the top of the mattress is about
waist high.
2. Turn the mattress wings inward.
3. Pivot the foot supports laterally.
• Grasp the handles, and
hold the foot section as
close to the body as
possible.
• Lift-Off Foot Section: Lift
and slide the foot section
toward you (bending your
knees) while taking a step
backward.
Lift-off Fluid Basin
Stow and Go® Foot Section
Fluid Basin
