Accessories
Affinity® 4 Birthing Bed Instructions for Use (USR025 REV 13) 33
The maximum safe working load is 60 lb (27 kg).
HEADBOARDS—P3617, P3629, P923617 AND P933617
The P3629 blow-molded headboard is available in five woodgrain laminate options and two color
laminate options. The P3617 contemporary wood headboard and P933617 FreedomHill™ wood
headboards are available in light and medium oak stain options. The P923617 LibertyHill™ wood
headboard is available in wild cherry and dark cherry stain options. All of the wood headboards are
available in all wood finishes.
INSTRUMENT TRAY—P278
The instrument tray is designed to optimize the process of performing
obstetrical postpartum procedures. This instrument tray is compatible with
lift-off and slide-off foot sections.
Location
The instrument tray is located at the foot section of the bed, in the foot
section yoke.
Warning—The instrument tray is for medical equipment only. Do not stand or sit on the instrument
tray. Do not place an infant on the instrument tray. Personal injury can occur.
The maximum safe working load is 25 lb (11 kg).
The Instrument Tray is not available on the Affinity® 4 Birthing Bed that has the Stow and Go® Foot
Section option.
INFUSION SUPPORT SYSTEM (ISS)—P158 AND P159
The P158 transfer pole and the P159 offset bar provide placement of infusion support devices and may
be located at either side of the head section.
The maximum safe working load is 40 lb (18 kg).
LABOR BAR—P3613
For extra support, the labor bar fits into the leg support sockets between the
seat and foot cushions.
To Adjust
• To raise or lower the bar, use the Foot controls. The bar can be used
in either direction for different positions and purposes.
The maximum safe working load is 100 lb (45 kg).
OXYGEN TANK HOLDER—P27605
The oxygen tank holder attaches to the frame in a vertical position. It holds one standard (E size) oxygen
tank.
The maximum safe working load is 30 lb (14 kg).
