Affinity® 4 Birthing Bed Instructions for Use (USR025 REV 13) i

QUICK VIEW™ LIST OF BED FEATURES

Item Description Item Description

A V-cut or straight-cut mattress I 8° trend-like position

B Lift-off, Stow and Go® Foot Section or

Slide off foot section

a. Slide off foot section no longer available.

J One-handle siderail release

C EasyGlide® Calf Supports K Removable headboard

D OneStep® Foot Supports L Lockout indicator

E Fluid basin M Battery indicator

F Central brake and steer pedal N Siderail lighting control (optional)

G Storable labor grips O Air support system (optional)

H CPR feature P Siderail communications package,

(optional)

Patient-Side Control

Caregiver-Side Control

Quick View™ List of Bed Features3
Revision4
Table of Contents7
Intended Use11
Introduction11
Safety Information12
Symbols13
- Product Symbols14
Point-Of-Care® Bed Controls20
- Caregiver Bed Controls20
  - Bed Up/Down (Hilow)20
  - Lockout Controls21
- Caregiver and Patient Bed Controls21
- Patient Bed Controls23
  - TV On/Off (Optional)23
Bed Frame Features23
- Central Brake and Steer23
- Automatic Tilt24
- CPR Release24
- Fluid Basin24
- Foot Section (Lift-Off or Slide-Off)24
- Stow and Go® Foot Section26
- Onestep® Foot Supports27
- Headboard27
- Pole27
- Labor Grips28
- Night Light28
- Battery Backup28
- Battery Sleep29
- Siderails29
- Trend-Like Function30
Optional Features30
- Air Support System30
- Seat Support30
- Lumbar Support30
- Siderail Controls31
- Built-In Sidecom® Communication System Controls (Optional)31
- Built-In Siderail Controls31
- Casters31
- Calf Support31
Mattresses31
- Mattress Models32
  - Non-Air Mattress32
- Wood Headboards32
Patient Positioning-Labor and Birth32
- Upright Position/Voiding Position33
- Lateral Position (Sims)33
- Kneeling Position33
- Legs Elevated with Foot Mattress34
- Squatting with the Labor Bar34
- Pushing with the Labor Bar34
- Pushing with the Labor Bar (with Foot Supports)34
- Pushing with Calf Supports35
- Epidural/Spinal (Lateral Approach)35
- Epidural (Sitting Approach)35
- Straight Line Trend-Like Positioning36
  - General Anesthesia36
- Throne Position (Chair)36
- Birthing Bed Mode36
- Delivery Table Mode37
  - With Calf Supports37
  - With Full Leg Supports37
- High Modified Trend-Like Position (Birth and Repair)37
Transport the Patient37
- Transport Safety Information38
Accessories39
- Anesthesia Screen-P9625 (no Longer Available)40
- Arm Board-P9620 (no Longer Available)40
- Calf Supports-P3705, and P3574541
- Comfort Pad-P3612TPA41
- Disposable Funnel Drape-P783441
- Foley Hook Kit-P362342
- Foot Rest Bar-P45142
- Full Leg Supports-P7625 and P763442
- Headboards-P3617, P3629, P923617 and P93361743
- Instrument Tray-P27843
- Infusion Support System (ISS)-P158 and P15943
- Labor Bar-P361343
- Oxygen Tank Holder-P2760543
- Pendant Control Kit with Holder-P5362, P3618 (no Longer Available)44
- Permanent IV Pole-P22210144
- Procedural Light-P7925D12044
- Rail and Hanger-P53120120 and P1707300144
- Sheets-SA1528, SA4585, SA1529, and SA458644
- Slipcovers (Head and Foot)-P3628, P3627, P3630 and P363144
- Slipcover Upgrade Kits-P3730 and P373145
- Push Handles-P1983A0145
- Line Manager-P373346
- Permanent IV Pole-P373247
Cleaning and Disinfecting48
- Recommendations48
- Cleaning and Disinfection49
- Care of Wood Components51
- Mattress Care and Draping51
Preventive Maintenance52
Decommissioning and Disposal Instructions53
Expected Life53
Troubleshooting54
- Power Loss54
Specifications54
- Electromagnetic Emissions Guidance59
