Specifications
Affinity® 4 Birthing Bed Instructions for Use (USR025 REV 13) 45
Specifications
Feature Dimension
Overall Length (maximum) 90" (229 cm) (B through C model beds)
92" (234 cm) (D model and newer beds)
Length from roller bumpers to break in seat section 61 7/8” (157 cm)
Length from break in the seat section to end of bed 28 1/8” (71 cm)
Maximum Width (siderails stored) 36" (91 cm)
Maximum Width (siderails up) 39" (99 cm)
Maximum Headboard Height 52" (132 cm)
Maximum Siderail Height (without mattress) 14¾” (37.47 cm)
Minimum Under-Bed Clearance 5" (13 cm), 3" (7.62 cm) for Stow and Go® foot
sections
Wheel Base 50" (127 cm) x 29" (74 cm)
Mattress Width 35" (89 cm)
Mattress Length 78" (198 cm)
Mattress Thickness (head/seat) 5" (12.7 cm)
Mattress Thickness (foot) 3.5" (8.9 cm)
Detachable Power Cord, IEC 320/interface US, 84" (213 cm)/international, 98" (248.9 cm)
Caster Size 6" (15 cm) or 8" (20 cm)
Head Section Inclination (maximum) 63°
Seat Section Inclination (maximum) 15°
Bed Height Range (Lift-off foot section) 19.0-33.75” (48.3-85.7 cm)
Bed Height Range (Stow and Go® foot section) 19.5-33.75” (49.5-85.7 cm)
Bed Height Range (Lift-off with mattress) 24.0-38.75” (60.9-98.4 cm)
Bed Height Range (Stow and Go® with mattress) 24.5-38.75” (62.2-98.4 cm)
Trend-Like position (maximum) 8°
Bed Lift capacity (safe working load)
a
a. Bed lift capacity (safe working load) includes mattresses, headboard, patient weight, any accessories or
equipment on the bed, caregiver weight, and any visitors sharing the bed.
500 lb (227 kg)
Maximum patient weight 470 lb (213 kg)
Foot Section Lift capacity (maximum) 400 lb (181 kg)
Head Section Lift capacity (maximum) 200 lb (91 kg)
Maximum Height of Seat Section (in Trend-Like
position)
40" (102 cm)
