Specifications
Compella™ Bariatric Bed System Instructions for Use (178951 REV 6) 93
Bed and Surface Air Supply Unit AC Power Requirements (120 V Model)
Bed and Surface Air Supply Unit AC Power Requirements (230 V Model)
Air Supply Unit Fuse Specifications
1
Applied Parts (in accordance with IEC 60601-1)
Condition Range
Rated Voltage
Bed 100/110/115/120/127 V AC
Air supply unit 110/115/120 V AC
Maximum Current
Bed 12 A
Air supply unit 1.2 A
Frequency
Bed 50/60 Hz
Air supply unit 50/60 Hz
Condition Range
Rated Voltage
Bed 220/230/240 V AC
Air supply unit 220/230/240 V AC
Maximum Current
Bed 6 A
Air supply unit 0.6 A
Frequency
Bed 50/60 Hz
Air supply unit 50/60 Hz
Fuse Type
120 V and 230 V models 3.15 A, 250 V, fast acting
1. There are no user accessible fuses for the bed. Refer to the Compella™ Bariatric Bed System Service Manual (178952)
for fuse ratings and replacement procedures.
Applied Parts
Siderail Headboard
Footboard Patient pendant
Sleep deck Support surface
