Symbols
Compella™ Bariatric Bed System Instructions for Use (178951 REV 6) 3
CPR instruction label—shows how to operate the CPR function on
the bed frame (1) and air supply unit (2) (page 21)
CPR mechanism label for the air surface—shows the direction to
turn the CPR mechanism to deflate the surface (page 21)
CPR control label for the bed frame—shows how to operate the
CPR control to lower the head section (page 21)
Caregiver Control Panel
Nurse Call control (page 53)
Service Required indicator (page 20)
Bed battery charge status (page 19)
Chair position control (page 29)
Bed flat control (page 29)
Tilt control (page 29)
Reverse tilt control (page 29)
