Symbols
4 Compella™ Bariatric Bed System Instructions for Use (178951 REV 6)
Width retract control and indicator (page 34)
Width extend control and indicator (page 34)
Err 6 (Bed width alert)—Fully expand or retract the bed width
(page 34)
FlexAfoot™ bed length adjustment (page 35)
Bed Up and Down controls (page 28)
Bed Not Down indicator—comes on when the upper frame is not in
the lowest position (page 28)
Head Up and Down controls (page 28)
Symbol Description
