Hillrom Compella - Standard Features; CPR Controls

Symbols
Compella™ Bariatric Bed System Instructions for Use (178951 REV 6) 7
Indicators on the Siderails
Hip Position Locator (on earlier versions of the bed) (page 20)
Head Pivot Locator (page 20)
Tilt/Reverse Tilt angle (page 21)
Head angle (page 21)
Patient Controls
Nurse Call control (page 53)
Head Up and Down controls (page 28)
Knee Up and Down controls (page 28)
Nurse Call Voice indicator (page 53)
Symbol Description
