Symbols
8 Compella™ Bariatric Bed System Instructions for Use (178951 REV 6)
Nurse Call Listening indicator (page 53)
IntelliDrive® XL Transport System Transport Pod
IntelliDrive Battery Charge indicator (page 36)
Disengage Transport Position control—raises the bed so the drive
wheels raise off the ground (page 36)
Transport Position control and indicator—lowers the bed to the
transport position (the drive wheels are on the ground) (page 36)
Steer pedal indicator (page 36)
Bed Frame
Shows how to raise the push handles (page 36 or 41)
Shows how to stow the push handles (page 36 or 41)
Before Transport sequence (page 36)
After Transport sequence (page 36)
Identifies the manual width adjustment control (page 34)
Symbol Description
