HIMA HIMatrix Series User Manual

7 Start-Up System Manual Compact Systems
Page 60 of 110 HI 800 141 E Rev. 2.02
7.3.3 Configuring the User Program
The following user program switches and parameters can be set in the Properties dialog box of
the user program:
Switch /
Parameter
Function
Default
value
Setting for
safe operation
Name
Name of the user program
Arbitrary
Program ID
ID for identifying the program when displayed in SILworX,
0…4 294 967 295.
If Code Generation Compatibility is set to SILworX V2,
only the value 1 is permitted. (These settings are required
for standard devices and modules).
0
Application-
specific
Priority
Only applicable with F*03!
Priority of the user program: 0...31, if multitasking is used
0
Application-
specific
Program's
Maximum Number
of CPU Cycles
Maximum number of CPU cycles that a user program
cycle may encompass.
A value greater than 1 is only allowed for HIMatrix
controllers F*03!
1
Application-
specific
Max. Duration for
Each Cycle [µs]
Maximum time in each processor module cycle for
executing the user program: 1...4 294 967 295 µs.
Set to 0: No limitation.
A value other than 0 µs is only allowed for HIMatrix
controllers F*03!
0 µs
0 µs
Watchdog Time
[ms] (calculated)
Monitoring time of the user program, calculated from the
Program's Maximum Number of Cycles and the watchdog
time of the resource
Not changeable!
-
i
For HIMatrix F*03 systems with counter inputs,
ensure that the user program's watchdog time is
less than or equal to 5000 ms.
Classification
Classification of the user program: Safety-related or
Standard (for documentation only).
Safety-
related
Application-
specific
Allow Online
Settings
It enables changes of other user program switches during
operation.
It only applies if the Allowed Online Settings switch for the
resource is set to ON!
ON
-
Autostart
Enabled type of Autostart: Cold Start, Warm Start, Off
Warm
start
Application-
specific
Start Allowed
ON:
The PADT may be used to start the user program.
ON
Application-
specific
OFF:
The PADT may not be used to start the user
program
Test Mode Allowed
ON
The test mode is permitted for the user program.
OFF
Application-
specific
OFF
The test mode is not permitted for the user program.
Reload Allowed
ON:
User program reload is permitted
ON
Application-
specific
OFF:
User program reload is not permitted
Local Forcing
Allowed
ON:
Forcing permitted at program level
OFF
OFF is
recommended
OFF:
Forcing not permitted at program level
Local Force
Timeout Reaction
Behavior of the user program after the forcing time has
expired:
 Stop Forcing Only.
 Stop Program.
Stop
Forcing
Only.
Application-
specific
Code Generation
Compatibility
SILworX V4
Code generation is compatible with
SILworX V4.
SILworX
V4 with
new
projects
SILworX V2 with
CPU OS V7
SILworX V4 with
CPU OS V8
SILworX V3
Not applicable for HIMatrix controllers!
SILworX V2
Code generation is compatible with
SILworX V2.
