Page #59 background image
System Manual Compact Systems 7 Start-Up
HI 800 141 E Rev. 2.02 Page 59 of 110
Variable
Description
Data
Type
Temperature state
Bit-coded temperature state of the processor system
Value
State
0x00
Normal temperature
0x01
Temperature threshold 1 exceeded
0x03
Temperature threshold 2 exceeded
0xFF
Not available
BYTE
Remaining Global Force
Duration [ms]
Time in ms until the time limit set for global forcing expires.
DINT
Watchdog Time [ms]
Maximum permissible duration of a RUN cycle in ms.
UDINT
Cycle Time, last [ms]
Current cycle time in ms
UDINT
Cycle Time, max [ms]
Maximum cycle time in ms
UDINT
Cycle Time, min [ms]
Minimum cycle time in ms
UDINT
Cycle Time, average [ms]
Average cycle time in ms
UDINT
Table 32: Hardware System Variables for Reading the Parameters
7.3.1.5 Rack System Parameter Settings
The rack system parameters can be set in the Rack's online view.
Parameter
Description
Default
value
Type
Spare, not changeable
-
Name
Rack name for the controller, text
HIMatrix
F...Rack
Rack ID
Not changeable
0
Temperature Monitoring
With F*03 devices only!
Specifies the temperature threshold that, if exceeded, causes a
warning message to be created:
Warning at temperature thresholds 1 and 2
Warning at temperature threshold 2 only
Warning at temperature threshold 1 only
No warning at temperature thresholds 1 and 2
Warning at
temperature
thresholds 1
and 2
Table 33: System Parameters of the Rack
7.3.2 Configuring the Ethernet Interfaces
Ethernet interfaces are configured in the Detail View of the communication module. If the
remote I/Os have no communication module, the Ethernet interfaces are configured in the Detail
View of the processor module. Refer to the manuals of the HIMatrix controllers and remote I/Os
for more details.
