Variable
Description
Data
Type
OFF:
The subordinate enable switches cannot be changed
online.
Read-only in RUN
ON:
The operator actions: Stop, Start, Download are locked.
BOOL
OFF:
The operator actions: Stop, Start, Download are not
locked.
Reload Release
With F*03 devices only!
BOOL
ON:
Controller can be loaded by performing a reload
OFF:
Controller cannot be loaded by performing a reload
Reload Deactivation
With F*03 devices only!
BOOL
ON:
Loading by performing a reload is locked
OFF:
Loading by performing a reload is possible
Reload Cycle
With F*03 devices only!
TRUE during the first cycle after a reload, otherwise FALSE
BOOL
CPU Safety Time [ms]
Safety time set for the controller in ms
UDINT
Start Allowed
ON:
Start of processor system using PADT is allowed
BOOL
OFF:
Start of processor system using PADT is not allowed
Start Cycle
ON during the first cycle after starting, otherwise OFF
BOOL
Power Supply State
Bit-coded state of the power supply units.
Compact controllers and remote I/Os:
Value
State
0x00
Normal
0x01
Undervoltage with 24 V supply voltage
0x02
(Low voltage with battery) not used
0x04
Low voltage with internally generated 5 V voltage
0x08
Low voltage with internally generated 3.3 V voltage
0x10
Overvoltage with internally generated 3.3 V voltage
F60 modular controller:
Value
State
0x00
Normal
0x01
Error with 24 V supply voltage
0x02
Battery failure
0x04
Error with 5 V voltage of power supply
0x08
Error with 3.3 V voltage of power supply
0x10
Undervoltage with 5 V voltage
0x20
Overvoltage with 5 V voltage
0x40
Undervoltage with 3.3 V voltage
0x80
Overvoltage with 3.3 V voltage
BYTE
System ID [SRS]
System ID of the controller, 1...65 535
UINT
Systemtick HIGH
Revolving millisecond counter (64-bit)
UDINT
Systemtick LOW
UDINT
