HIMA HIMatrix Series User Manual

System Manual Compact Systems 7 Start-Up
HI 800 141 E Rev. 2.02 Page 75 of 110
Column
Description
Range of values
LL Alarm
Acknowledgment
Required
Activated
The user must confirm that the lowest limit (LL) has
been exceeded (acknowledgment).
Deactivated
The user may not confirm that the lowest limit (LL)
has been exceeded.
Default value: Deactivated
Checkbox activated,
deactivated
Alarm Hysteresis
The hysteresis avoids that many events are continuously created
when the process value often oscillate around a limit.
Depending on the
global variable type
Table 45: Parameters for Scalar Events
NOTE
Faulty event recording due to improper parameter settings possible!
Setting the parameters L Alarm Value and H Alarm Value to the same value can cause an
unexpected behavior of the event recording since no normal range exists in such a case.
For this reason, make sure that L Alarm Value and H Alarm Value are set to different
values.
7.7 Configuring a Resource Using ELOP II Factory - CPU OS up to V7
This chapter describes the various configuration options using ELOP II Factory for processor
operating systems up to V7.
7.7.1 Configuring the Resource
The first step is to configure the resource. The parameter and switch settings associated with
the configuration are stored to the NVRAM of the processor system and to the flash memory of
the communication system.
The following system parameters can be set for a resource:
Parameter
Range
Description
Default value
System ID [SRS]
1...65 535
System ID within the network
0 (invalid)
Safety Time [ms]
20...50 000 ms
Safety time of the controller
(not of the entire process)
Watchdog
Time
Watchdog Time
[ms]
 10 ms
 (Safety
Time) / 2
 5000 ms
Maximum time allowed for a PES RUN
cycle.
If the cycle time has been exceeded, the
controller enters the STOP state.
Controller:
50 ms
Remote I/O:
10 ms
Main Enable
On/Off
The main enable switch can only be set to
ON if the controller is in the STOP state.
It allows the user to modify the settings for
the following switches and the parameters
Safety Time and Watchdog Time in the RUN
state.
On
Autostart
On/Off
Automatic start of the controller after its
powering ON (automatic transition from
STOP to RUN)
Off
Start/Restart
Allowed
On/Off
Start command for the controller
On
On:
Start (cold start) or restart (warm start)
commands accepted by the controller
Off:
Start/restart not allowed
Load Allowed
On/Off
User program load
On
On:
Load Allowed
