System Manual Compact Systems 9 Maintenance
HI 800 141 E Rev. 2.02 Page 97 of 110
4. The context menu opens. Click Maintenance/Service->Load Module Operating System.
5. In the dialog box Load Module Operating System, select the type of the operating system to
be loaded.
6. A dialog box for selecting a file opens. Select the file with the operating system that should
be loaded and click Open.
SILworX loads the new operating system into the controller.
9.2.2 Loading the Operating System with ELOP II Factory
Use the ELOP II Factory programming tool if the operating system version loaded in the
controller is up to 7.
To load the new operating system
1. Set the controller to the STOP state, if it has not already been done.
2. Log in to the controller with administrator rights.
3. In ELOP II Factory Hardware Management, right click the required resource.
4. On the Online submenu, select Control Panel.
The Control Panel opens.
5. On the Extra menu, OS Update submenu, select the type of operating system that should
be loaded (processor operating system, communication operating system).
A dialog box for selecting a file opens.
6. In this dialog box, move to the directory in which the operating system is stored and select it.
7. Click OK to load the operating system.
The operating system is loaded into the controller. The controller restarts and enters the STOP
state.
After an operating system has been loaded, the controller also enters the STOP state if a
program is loaded with the Autostart safety parameter set to TRUE.
The following is possible:
Repeating the described sequence, further operating systems can be loaded, e.g., the
operating system for the communication system, after the operating system for the processor
system.
The controller can be set to the RUN state.
9.2.3 Switching between ELOP II Factory and SILworX - not with F*03
HIMatrix controllers (except for F*03 devices and modules) can either be programmed with
ELOP II Factory or with SILworX, if the appropriate version for the operating system is installed.
The combinations of programming tool and operating system version are specified in the table.
Version for ELOP II Factory
Table 66: Operating System Versions and Programming Tools
9.2.3.1 Upgrading from ELOP II Factory to SILworX
This upgrade may only be used for HIMatrix controllers and remote I/Os with newer layouts. Any
attempt to use it with controllers and remote I/Os with previous layouts leads to failures that can
only be removed by HIMA.
