Hirschmann BRS20-0400 Series User Manual

Installation BRS20/30/40/50
Release 02 11/2018
27
BRS20-0900xx99-xxC...
1 6-pin terminal block with screw lock for redundant power supply and signal contact
2 2-pin terminal block with screw lock for the digital input
3 USB-C interface
4 8 × RJ45 socket for 10/100 Mbit/s Twisted pair connections
5 LED display elements for port status
6 Rail lock slide for DIN rail mounting
7 Grounding screw
8 Label area for IP address
9 depending on device variant
DSC or DST singlemode socket for 100 Mbit/s fiber optic connections
DSC or DST multimode socket for 100 Mbit/s fiber optic connections
10 LED display elements for port status
11 LED display elements for device status
Power
Status
ACA
3
1
2
4
6
5
11
7
10
9
USB
IP-ADRESS
1
2
3
4
5
6
7
8
9
Input
8
