Hirschmann qSCALE i2 Service Manual

Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 80/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
Error
Code
Description
Cause
Notice/Solution
1F3F
Version Error
The versions of the load charts / data
programming are incompatible with the
application
Call Customer Service to have the unit
or software replaced
1F40
Power supply
System supply voltage is too Low
Check the battery voltage and the
power supply wiring
1F41
Battery voltage
Buffered battery voltage is too Low
Call Customer Service to have the unit
replaced
1F42
Warning temperature
Power supply temperature is too High
Check the system's installation. Try
turning the Ignition off and on again.
Consult Customer Service if the error
occurs again
1F43
Warning temperature
CPU temperature is too High
Check the system's installation. Try
turning the Ignition off and on again.
Consult Customer Service if the error
occurs again
1F44
CAN bus network error
CAN bus failure
Check the CAN cabling and supply
voltage. Try turning the Ignition off and
on again. Consult Customer Service if
the error occurs again
1F4F
Version Error
The versions of the parameter data and
the application are incompatible
Call Customer Service to have the unit
or software replaced
1FFF
Fatal safety error
Unrecoverable RAM or FLASH memory
failure - the system is unsafe
Turn the Ignition off and on again.
Consult Customer Service if the error
occurs again
2000
Module Error
Command line error
Turn the Ignition off and on again.
Consult Customer Service if the error
occurs again
2001
Module Error
Project - load failure
Turn the Ignition off and on again.
Consult Customer Service if the error
occurs again
2002
Module Error
Machine model - load failure
Turn the Ignition off and on again.
Consult Customer Service if the error
occurs again
2003
Module Error
Operating Mode - load failure
Turn the Ignition off and on again.
Consult Customer Service if the error
occurs again
2004
Module Error
Interface initialization failure
Turn the Ignition off and on again.
Consult Customer Service if the error
occurs again
2005
Module Error
Data read/write failure
Turn the Ignition off and on again.
Consult Customer Service if the error
occurs again
2010
Module Error
Operating mode selection error
Select a valid Operating Mode
2011
Module Error
Machine model selection error
Select a valid Operating Mode
2014
Module Error
Machine model selection error
Select a valid Operating Mode
2015
Module Error
Operating mode selection error
Select a valid Operating Mode
