Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 87/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
Max temperature limit
exceeded
Ambient temperature
above the upper user limit
(HMI or external control)
Operation is restricted to permitted
conditions
Min radius limit un-
derrun
Booming up beyond the
inner radius limit (user pre-
warning preset / 'Grey
Zone' - HMI or external
control)
Move the Jib down to a valid radius
and angle
Max radius limit ex-
ceeded
Booming down outside the
radius limit (user pre-
warning preset / 'Grey
Zone' - HMI or external
control)
Boom up to a valid radius and angle
Booming down below the
lower angle limit (user pre-
warning preset / 'Grey
Zone' - HMI or external
control)
Boom up to a valid radius and angle
Booming up beyond the
upper angle limit (user pre-
warning preset / 'Grey
Zone' - HMI or external
control)
Move the Jib down to a valid radius
and angle
Booming down below the
lower angle limit (user pre-
warning preset / 'Grey
Zone' - HMI or external
control)
Move the jib up to a valid radius or
angle
Booming up beyond the
upper angle limit (user pre-
warning / 'Grey Zone' -
HMI or external control)
Move the jib down to a valid radius
or angle
Booming down below the
lower angle limit (user pre-
warning preset / 'Grey
Zone' - HMI or external
control)
Move the jib up to a valid radius or
angle
Booming up beyond the
upper angle limit (user pre-
warning / 'Grey Zone' -
HMI or external control)
Move the jib down to a valid radius
or angle
Slewing outside the Work-
ing Range limit (user pre-
warning / 'Grey Zone' -
HMI or external control)
Rotate to the permitted Working
Range
Slew angle right to large
Slewing outside the Work-
ing Range limit (user pre-
warning / 'Grey Zone' -
HMI or external control)
Rotate to the permitted Working
Range
