Hirschmann qSCALE i2 Service Manual

Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 88/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
Error
Code
Description
Cause
Notice/Solutions
016C
Global Cut
Min length limit un-
derrun
Telescoping below the
Working Range limit (user
pre-warning / 'Grey Zone' -
HMI or external control)
Telescope into the permitted Work-
ing Range
026C
Single Cut
036C
Error
046C
Warning
056C
Pre-Warning
016D
Global Cut
Max length limit ex-
ceeded
Telescoping beyond the
Working Range limit (user
pre-warning / 'Grey Zone' -
HMI or external control)
Telescope into the permitted Work-
ing Range
026D
Single Cut
036D
Error
046D
Warning
056D
Pre-Warning
016E
Global Cut
Min height limit un-
derrun
Descending below the
Working Range limit (user
pre-warning / 'Grey Zone' -
HMI or external control)
Move the boom into the permitted
Working Range (load chart)
026E
Single Cut
036E
Error
046E
Warning
056E
Pre-Warning
016F
Global Cut
Max height limit ex-
ceeded
Elevation above the user
Working Range limit - User
pre-warning / 'Grey Zone'
Move the boom into the permitted
Working Range
026F
Single Cut
036F
Error
046F
Warning
056F
Pre-Warning
0170
Global Cut
Min wind speed limit
underrun
Wind Speed below the
lower limit (user pre-
warning / 'Grey Zone' -HMI
or external control)
Operation is restricted to permitted
conditions
0270
Single Cut
0370
Error
0470
Warning
0570
Pre-Warning
0171
Global Cut
Max wind speed limit
exceeded
Wind Speed above the
upper limit (user pre-
warning / 'Grey Zone' -
HMI or external control)
Operation is restricted to permitted
conditions
0271
Single Cut
0371
Error
0471
Warning
0571
Pre-Warning
0172
Global Cut
Min temperature limit
underrun
Ambient temperature
below the lower limit (user
pre-warning / 'Grey Zone' -
HMI or external control)
Operation is restricted to permitted
conditions
0272
Single Cut
0372
Error
0472
Warning
0572
Pre-Warning
0173
Global Cut
Max temperature limit
exceeded
Ambient temperature
above the upper limit (user
pre-warning / 'Grey Zone' -
HMI or external control)
Operation is restricted to permitted
conditions
0273
Single Cut
0373
Error
0473
Warning
0573
Pre-Warning
0174
Global Cut
Superstructure Inclina-
tion
The superstructure has
exceeded the maximum
inclination angle
Relevel the superstructure
0274
Single Cut
0374
Error
0474
Warning
0574
Pre-Warning
01A0
Global Cut
Min load limit on outrig-
ger underrun front left
Load on Outrigger too Low
(tilting danger)
Move the boom into the permitted
Working Range (load chart)
02A0
Single Cut
03A0
Error
04A0
Warning
05A0
Pre-Warning
01A1
Global Cut
Max load limit on outrig-
ger reached front left
Load on Outrigger too High
(outrigger damage)
Move the boom into the permitted
Working Range (load chart)
02A1
Single Cut
03A1
Error
04A1
Warning
05A1
Pre-Warning
