Hirschmann qSCALE i2 Service Manual

Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 93/161
qSCALE i2 Cranes (Tool Version 3.0.34) Service Manual / Issue B / 11-2017 / ac.
0A54
Invalid Outrigger
Invalid outrigger position for the
current operating mode
Check the sensors and actuators. Select a
correct Operating Mode
0A55
Invalid bolting
The locking pin selection does
not match operating mode
Check the sensors and actuators. Select a
correct Operating Mode
0A56
Invalid counterweight
Invalid operating counterweight
value
Check the sensors and actuators. Select a
correct Operating Mode
0A57
Invalid winch configuration
The winch selection does not
match the operating mode
Check the sensors and actuators. Select a
correct Operating Mode
0A58
Invalid main boom configu-
ration
The boom selection does not
match the operating mode
Check the sensors and actuators. Select a
correct Operating Mode
0A59
Invalid criteria
The application produced an
invalid result
Check the sensors and actuators. Select a
correct Operating Mode
0A5A
Operating under a load
The current operating mode
does not allow the machine to
be loaded
Remove all load from the machine
0A5B
Invalid capacity utilization
Zero or invalid utilization
Check and correct the predicted loads of the
load chart
0A61
Invalid feasible operation
mode
The current operating mode is
not available at this time for
application specific reasons
Check the sensors and actuators. Select a
correct Operating Mode
0A62
Invalid feasible operation
mode
The current operating mode is
not available at this time for
application specific reasons
Check the sensors and actuators. Select a
correct Operating Mode
0A63
Invalid feasible operation
mode
The current operating mode is
not available at this time for
application specific reasons
Check the sensors and actuators. Select a
correct Operating Mode
0A64
Invalid feasible operation
mode
The current operating mode is
not available at this time for
application specific reasons
Check the sensors and actuators. Select a
correct Operating Mode
0A65
Invalid feasible operation
mode
The current operating mode is
not available at this time for
application specific reasons
Check the sensors and actuators. Select a
correct Operating Mode
0A66
Invalid feasible operation
mode
The current operating mode is
not available at this time for
application specific reasons
Check the sensors and actuators. Select a
correct Operating Mode
0A67
Invalid feasible operation
mode
The current operating mode is
not available at this time for
application specific reasons
Check the sensors and actuators. Select a
correct Operating Mode
0A68
Invalid feasible operation
mode
The current operating mode is
not available at this time for
application specific reasons
Check the sensors and actuators. Select a
correct Operating Mode
0A6A
Invalid value
Negative Radius was computed
Check the sensors and actuators. Data Pro-
gramming does not cover the operating state.
Consult Customer Service if the error occurs
again
0A6B
Invalid value
Negative Height was computed
Check the sensors and actuators. Data Pro-
gramming does not cover the operating state.
Consult Customer Service if the error occurs
again
0A6C
Invalid value
Negative Length was computed
Check the sensors and actuators. Data Pro-
gramming does not cover the operating state.
Consult Customer Service if the error occurs
again
0A70
Redundancy error
Length - redundancy error
Turn the Ignition off and on again. Consult
Customer Service if the error occurs again
0A71
Redundancy error
Height - redundancy error
Turn the Ignition off and on again. Consult
Customer Service if the error occurs again
0A72
Redundancy error
Radius - redundancy error
Turn the Ignition off and on again. Consult
Customer Service if the error occurs again
0A73
Redundancy error
Load - redundancy error
Turn the Ignition off and on again. Consult
Customer Service if the error occurs again
