Hirschmann qSCALE maestro User Manual

WIKA Mobile Control LP
1540 Orchard Drive
Chambersburg, PA 17201
qSCALE maestro (PLC v01.00.00) Service Manual / Issue E (HMI v1.0.0) 04/2018 / rbm.
Service : (717) 217-2250
Parts / Sales : (717) 217-2269
www.wika-mc.com
10 /76
HIRSCHMANN MCS
2.1.2 Pressure Sensor Kit (102121)
Component Name Part Number QTY
SENSOR,PRESS,SINGLE,CAN,ID 60 061091 1
SENSOR, PRESS TRANS, CAN,ID 61 061092 1
0935 253 103/5 M 10968 2
SENSOR ACCY, CUTTING RING DKA 000-209-140-016 2
HYDR, ADAPTER, BULKHEAD 9/16- 000-214-600-093 2
HYDR, ADAPTER, 9/16-18 UNF-2B; 031-300-050-689 2
HYDR, FITTING, 1/4 NPT MALE TO 031-300-050-750 2
2.2 Boom Upgrade (102124)
Component Name Part Number QTY Notes
STRAIN RELIEF, PG13.5/PG 9 000-214-261-309 1
STRAIN RELIEF ACCY, PFLITSCH RUBBER HOLE PLUG BO 4-
6.5MM
051292 2
STRAIN RELIEF ACCY, PFLITSCH RUBBER HOLE PLUG BO 9-13MM 051293 2
0935 253 103/15 M 27866 1
STRAIN RELIEF, PG13.5 HOLE 000-214-340-013 1
STRAIN RELIEF, PG11/PG 9 000-214-261-109 1
STRAIN RELIEF, PG11 HOLE PLUG 000-214-340-011 1
SENSOR ASSY, LENGTH/ANGLE, WGX/CAN 061185 1 Section 2.2.1
SCREW, 6mm X 12mm SOCKET CAP 002-050-206-012 3
WASHER, FLAT 6MM 000-207-010-064 3
SENSOR, LENGTH POT.W/O 067-000-100-204 1
