Hirschmann qSCALE maestro User Manual

WIKA Mobile Control LP
1540 Orchard Drive
Chambersburg, PA 17201
qSCALE maestro (PLC v01.00.00) Service Manual / Issue E (HMI v1.0.0) 04/2018 / rbm.
Service : (717) 217-2250
Parts / Sales : (717) 217-2269
www.wika-mc.com
9 /76
HIRSCHMANN MCS
2.1.1 Junction Box, qSCALE maestro (061179)
Component Name Part Number QTY
JUNCTION BOX, 160x240X81 061180 1
TERMINAL STRIP ACCY, RAIL MAESTRO 9IN 051295 1
HARNESS, QSCALE MAESTRO CONTROLLER TO JUNCTION BOX 061178 1
WASHER, LOCK 1/4 000-208-040-070 2
TERMINAL STRIP ACCY, BLOCK, PIK 4N W/BAR 051296 7
TERMINAL STRIP ACCY, BLOCK, PIK 4N WO/BAR 051297 12
TERMINAL STRIP ACCY, BLOCK PIK 4N W/DIODE 061181 1
EC, DIODE, 1N4003 200V/1A 000-430-104-003
TERMINAL STRIP ACCY, END PLATE, PIK 4N 051298 1
TERMINAL STRIP ACCY, END BRACKET, PIK 4N 051299 2
RELAY, SHUTOFF 12V 20/30A 000-304-140-112 1
EC, DIODE, 1N4003 200V/1A 000-430-104-003 2
KEYSWITCH, CENTRAL UNIT, NEW 024-350-100-768 1
CENTRAL UNIT ACCY, MEMBRANE 024-000-100-095 1
STRAIN RELIEF, PG13.5 12-15mm 021-441-161-213 1
STRAIN RELIEF, PG 9 4-6mm, 021-441-060-409 6
STRAIN RELIEF, PG 9 5.5mm, 021-441-090-709 1
TAPE, 3M, VHB 5925 1 031-300-050-765
STRAIN RELIEF, PG13.5 8-12mm 021-441-131-013 3
WIRE, HOOKUP 18 AWG BLUE 123-429-910-960 0.6 ft
WIRE, HOOKUP 20 AWG GREEN 123-429-901-830 0.6 ft
WIRE, HOOKUP 18 AWG BROWN 123-429-910-880 0.6 ft
WIRE, HOOKUP 18 AWG BLACK 123-429-907-280 3.6 ft
WIRING ACCY, CRIMP TERMINAL, 18-22AWG, INSULATED, RED 051304 4
