4.3.1 Calibrate Angle Sensors
Summary
This section describes how to calibrate the boom angle sensor. The machine must be on a level
surface to calibrate this sensor.
  
HOME SETTINGS SENSOR
CALIBRATION
ANGLE
SENSOR
CALIBRATION
Fully retract the boom and press
Fully lower the boom and press

