WIKA Mobile Control LP
1540 Orchard Drive
Chambersburg, PA 17201
qSCALE maestro (PLC v01.00.00) Service Manual / Issue E (HMI v1.0.0) 04/2018 / rbm.
Service : (717) 217-2250
Parts / Sales : (717) 217-2269
www.wika-mc.com
8
/76
HIRSCHMANN MCS
2 Components
Kit Name Kit Number QTY Section
BASE UPGRADE KIT W/ VSCALE D2 102125 1 Section 2.1
BASE UPGRADE KIT W/ VSCALE D3 102129 1 Section 2.1
BOOM UPGRADE (FROM EXISTING 200/208/209 REEL) 102124 1 Section 2.2
BOOM KIT, NEW CABLE REEL 102126 1 Section 2.3
INDICATOR, LIGHT TOWER, MAESTRO, 10M, 3 COLOR (RGY) 102127 1 Section 2.4
2.1 Base Kit with vScale D2 or D3 (102125/102129)
Component Name Part Number QTY Notes
SMC, POWER HARNESS, VSCALE CONSOLE, PWR ONLY, 12' 061106 1
SMC, CONSOLE, VSCALE, D2 - C1, 4.3" DISPLAY 608413 1 D2 kit only
SMC, CONSOLE, VSCALE, D3 - C2, 7", 3 CAM, 4x AI/DI, 3x DO 608416 1 D3 kit only
SMC, QSCALE MAESTRO S6, IP66/67 623029 1
JUNCTION BOX, QSCALE MAESTRO 061179 1 Section 2.1.1
0985 806 125/10M - 90 DEG BEND 900004191 1
ASBSV 4 5 P5 MCS CUSTOM 934637762 1
0935 253 103/3 10967 1
SCREW, SLOTTED PH 5mm x 16mm 002-050-206-112 11
NUT, 5MM HEX NYLON INSERT 031-300-050-468 11
WASHER, 5MM CONCAVE BELLVILLE 000-208-030-050 11
CONSOLE ACCY, KIT 2-1" BALL W/ 4.75" MTG. ARM 031-300-060-382 1 D2 kit only
CONSOLE ACCY, KIT 2 - 1.5 051170 1 D3 kit only
SMC, CONSOLE ACCY, RAM MOUNT ADAPTER, iSCOUT D2 608460 1 D2 kit only
SMC, CONSOLE ACCY, RAM MOUNT 608464 1 D3 kit only
SMC, DUMMY PLUG ASSY, 48-PIN 060980 1
BRACKET, EXTERNAL MOUNTING FEET 2/PACK, FOR MAESTRO 051309 1
SCREW M4X12MM NARROW HEAD PHILLIPS STAINLESS STEEL 051310 4
ZVK 12291 600000991 2
0909 UAC 101 600003038 2
KIT, QSCALE IX, LOAD, PSENS, DAVS, 300 BAR, SAE 6, ID 60/61 102121 1 Section 2.1.2
STRAIN RELIEF ACCY, PFLITSCH RUBBER HOLE PLUG BO 4-6.5MM 051292 7
STRAIN RELIEF ACCY, PFLITSCH RUBBER HOLE PLUG BO 9-13MM 051293 1
